Hob Module Manulift 6380HA-S4

  • Wall-mounted, manual adjustment
  • 103 mm front rim

Hob Module Manulift 6380LA-S4

  • Wall-mounted, manual adjustment
  • 40 mm front rim

Hob Module Manulift 6380HA-S4

Hob Module Manulift 6380LA-S4

Wall Mounted Manual Hob Module 6380HA-S4 - Left
Wall Mounted Manual Hob Module 6380HA-S4 - Left

Wall Mounted Manual Hob Module 6380HA-S4 - Left

Select model

Wall Mounted Manual Hob Module 6380HA-S4 - Left
Left
Wall Mounted Manual Hob Module 6380HA-S4 - Center
Center
Wall Mounted Manual Hob Module 6380HA-S4 - Right
Right

Lift Width

  • 79.0 cm
  • 99.0 cm
  • 119.0 cm
  • 139.0 cm
  • 159.0 cm

Planning Width

  • 80.0 cm
  • 100.0 cm
  • 120.0 cm
  • 140.0 cm
  • 160.0 cm

Accessories

Drawer, Baselift / Manulift
Drawer, 30 cm width
pcs
Drawer, 40 cm width
pcs
Drawer, 50 cm width
pcs
Drawer, 60 cm width
pcs
Drawer, 80 cm width
pcs
Drawer - Push-to-open
Drawer Push-to-open, 30 cm width
pcs
Drawer Push-to-open, 40 cm width
pcs
Drawer Push-to-open, 50 cm width
pcs
Drawer Push-to-open, 60 cm width
pcs
Drawer Push-to-open, 80 cm width
pcs
Cutlery compartment
Cutlery compartment, 30 cm width
pcs
Cutlery compartment, 40 cm width
pcs
Cutlery compartment, 50 cm width
pcs
Cutlery compartment, 60 cm width
pcs
Cutlery compartment, 80 cm width
pcs
Power Socket, Black (EU 2-pin)
Power Socket, Black (EU 2-pin)
pcs
Power Socket, Black (UK 3-pin)
Power Socket, Black (UK 3-pin)
pcs
Power socket, ALU-Design
Power socket, ALU-Design
pcs
Two-compartment frame, ALU-Design
Two-compartment frame, ALU-Design
pcs
Mini cabinet on wheels
Mini cabinet on wheels with drawer and inner drawer, fully extendable with soft-close
pcs

Your configuration
Description
Hob Module 6380HA-S4, Left incl. top board. Prepared for hob with 4 cooking zones, width 79 cm


Wall mounted, Manually Height Adjustable Hob Module. Prepared for glass ceramic hob with four cooking zones. Front height is 103 mm.

The module is available in left, centre, or right version.

The modules have a 10 mm shorter width to automatically give 5 mm gap on either side of the unit for the up and down movement. They are also 15 mm shallower in depth to make room for splash protection/tiles.

The module can be integrated into environments from any kitchen manufacturer.

Functions and Advantages

  • 30 cm height adjustment
  • Adjustable depth 576-606 mm incl. Front
  • Tiltable worktop plane for adjustment
